Components
These components, created with SASS, are the basic elements that make up the Rent Dynamics Admin tool. Effort should be made to reuse these components before resorting to creating custom elements.
Colors
Our colors consist of primary and neutral colors that are meant to provide emphasis to interface elements.
Typography
Text is the most important part of an interface, and as such, it should be easily readable. Below, you will find the SASS variable and HEX code for each color variation
Font stack
We've chosen the system font for our typeface. This helps provide a natural-feeling, native experience.
font-family: -apple-system, BlinkMacSystemFont, "Segoe UI", "Roboto", "Noto Sans", "Ubuntu", "Droid Sans", "Helvetica Neue", sans-serif;
Usage
Heading h1
Heading h2
Heading h3
Paragraph p
Heading h1
Heading h2
Heading h3
Paragraph p
Buttons
Here is the information for all the buttons
Standard button
Use the standard button for most cases. This allows for a lighter visual page weight. Two classes are available for ease-of-use: .btn
or .btn--standard
Standard
Standard
Primary button
Use the primary button to call attention to the strongest action on the form or page. Not every screen needs a primary action.
Primary
Link button
Use for secondary actions, and destructive actions such as “Cancel,” or to discourage/limit use.
Link button
Button variations
Use these button variations extremely sparingly for actions with disastrous consequences, or for unique circumstances.
Warning
Danger
Success
Disabled buttons
Use when an another action has to be completed before the button is usable.
Disabled
Disabled
Button group
Use groups when there is a close relationship to the actions. Normally used at the top of a page.
ButtonGroupYo!
Applying button classes
Buttons can be applied to the following elements: div
, a
, and button
.
Tabs
Tabs can be used to easily group together similar information on the same page. This allows content to be viewed without having to navigate away from the page.
Horizontal tabs
Use horizontal tabs to provide navigation at the highest page level. Horizontal tabs should take up the full width of their parent. Add the .active
class to indicate the currently selected tab.
Tab 1Tab 2Tab 3Users
Vertical tabs
Use vertical tabs to provide navigation at a sub-page level. Limit the container width to prevent connection being lost between the tab and the active highlight border. Add the .active
class to indicate the currently selected tab.
Tab 1Tab 2Tab 3Users
Tables
Use tables to display tabular data. Especially useful for documentation.
Table format
When using tables, add the .table
class, as well as a thead
and tbody
.
Table header 1 | Table header 2 | Table header 3 |
---|---|---|
Table data 1 | Table data 2 | Table data 2 |
Table data 1 | Table data 2 | Table data 3 |
Table data 1 | Table data 2 | Table data 3 |
Table header 1 | Table header 2 | Table header 3 |
---|---|---|
Table data 1 | Table data 2 | Table data 2 |
Forms
forms
Horizontal form
Use horizontal forms to speed up data entry. The label is right aligned with the text field. When applicable, you may use two columns to display two horizontal forms at once. Stacks when responsive. Although input fields fill to 100% of their parent, make sure to size them to fit the expected content.
this is helper, or read-only text
this is read-only text
Toggle switches
Toggles can be used to replace checkboxes. They represent a variety of states, including on/off, active/inactive, yes/no, etc. These toggle switches are purely HTML/CSS, so their functionality needs to be operated with Angular or jQuery.
Toggle label
Modals
Use modals to provide access to item-specific features. Modals allow for reduced navigation architecture and an ecapsulated experience.
Full screen modal
Full screen modals take up the full screen, with a max width of 1200px.
content
Launch modalModal title...
Responsive
We use the responsive grid system from Bootstrap 3 (http://getbootstrap.com/css/#grid). Columns must be contained within a
.row
element.
col-sm-6
col-sm-6
col-sm-4
col-sm-4
col-sm-4
Icons
Icons are hosted via an Icomoon icon font. Custom icons are based on a 24px grid. Icons inherit their styling from their parent element (e.g. font-size, color).
Icon | Class |
---|---|
|
.icon--rd |
|
.icon--check |
|
.icon--x |
|
.icon--heart |
|
.icon--heartCheck |
|
.icon--user |
|
.icon--officeBuilding |
|
.icon--apartmentBuilding |
|
.icon--townhomeBuilding |
|
.icon--menu |
Usage
Utilities
Various utilities to help layout the interface
Utility | Description |
---|---|
.pull--right |
Floats the element right |
.pull--left |
Floats the element left |
.clearfix |
Apply to a parent element to fit parent to its children |
.text--left |
Left aligns text within the element |
.text--center |
Center aligns text within the element |
.text--right |
Right aligns text within the element |
